To establish the project design basis for “Fiscal Metering Skids”, confirm “Fiscal measurement basis” and its inputs: Provide fluid and meter type, reference conditions, operating range, compensation and contractual measurement-record and traceability requirements. Final values, supply limits and acceptance criteria are recorded in approved engineering documents; no generic capacity or catalogue guarantee is assumed.
From project definition to delivery
Engineering of Fiscal Metering Skids concentrates on required measurement uncertainty, fluid properties, operating range, meter-run geometry, pressure loss, flow conditioning, calibration or proving, compensation and audit-trail integrity. The selected configuration is verified against normal, minimum, start-up, shutdown and credible upset cases, then checked for operability, maintainability, energy use, process safety and site interfaces before the design is frozen.
The design basis for Fiscal Metering Skids is defined from service data, design conditions, and battery limits. For this equipment, Fiscal measurement basis and Fluid and operating cases must be completed in the datasheet and design documents; performance values and guarantees are set only after the project basis is approved.
Materials, corrosion allowance, sour-service requirements, piping classes, nozzle design, insulation, coating, supports and maintenance access are coordinated with the actual process conditions and project code hierarchy.
Control philosophy, alarms and trips, cause-and-effect logic, interlocks, start-up and shutdown sequences, safe depressurization and operator access are developed consistently from the P&IDs through functional testing.
Battery limits, tie-in points, structural loads, cabling, instrumentation, drains, vents, access routes, lifting envelopes and shipping constraints are controlled through coordinated models and interface drawings.
From project definition to delivery
Proposal quality depends on complete input data and an explicit acceptance basis. The following lists provide a practical starting point and are completed during technical clarification.
Technical Datasheet
One ultrasonic meter family is shown as a reference for the primary element. The meter figures are not a complete station capacity or Delham fiscal-accuracy guarantee.
| Parameter | Published value | Basis / secondary data | Application limit |
|---|---|---|---|
| Ultrasonic meter line size / velocity | 4–42 in; Qmin 1.7 ft/s; Qmax 100/85/75 ft/s* | *Published Qmax: 100 ft/s for 4–24 in, 85 ft/s at 30 in, 75 ft/s at 36 in; confirm 42-in sizing from the current meter datasheet. | Published values for the 3414 ultrasonic meter family only; they do not rate the full skid or custody-transfer station. |
| Calibrated accuracy example | ±0.1% of reading | Published flow-calibrated accuracy across that meter's calibrated range. | Not a blanket station uncertainty or legal-metrology acceptance claim. |
Delham Engineering
Send the available process data, battery limits and expected document list for a technical proposal. The engineering team will identify missing information through a structured clarification register.
