Packages · Metering & Analyzer
To establish the project design basis for “Analyzer Packages”, confirm “Analyzer and stream coverage” and its inputs: Provide stream count, measured components, method, concentration range, sample points and required response time from the measurement basis. Final values, supply limits and acceptance criteria are recorded in approved engineering documents; no generic capacity or catalogue guarantee is assumed.
From project definition to delivery
Engineering of Analyzer Packages concentrates on sample representativeness, transport lag, phase integrity, pressure and temperature conditioning, filtration, calibration, analyzer response, shelter environment and hazardous-area requirements. The selected configuration is verified against normal, minimum, start-up, shutdown and credible upset cases, then checked for operability, maintainability, energy use, process safety and site interfaces before the design is frozen.
The design basis for Analyzer Packages is defined from service data, design conditions, and battery limits. For this equipment, Analyzer and stream coverage and Sample composition and range must be completed in the datasheet and design documents; performance values and guarantees are set only after the project basis is approved.
Materials, corrosion allowance, sour-service requirements, piping classes, nozzle design, insulation, coating, supports and maintenance access are coordinated with the actual process conditions and project code hierarchy.
Control philosophy, alarms and trips, cause-and-effect logic, interlocks, start-up and shutdown sequences, safe depressurization and operator access are developed consistently from the P&IDs through functional testing.
Battery limits, tie-in points, structural loads, cabling, instrumentation, drains, vents, access routes, lifting envelopes and shipping constraints are controlled through coordinated models and interface drawings.
From project definition to delivery
Proposal quality depends on complete input data and an explicit acceptance basis. The following lists provide a practical starting point and are completed during technical clarification.
Technical Datasheet
These are model-family examples, not a universal analyzer envelope, Delham rating, or project guarantee. Select the method and range for the measured component and sample matrix.
| Parameter | Published value | Basis / secondary data | Application limit |
|---|---|---|---|
| NO / NOx measurement range | 0–3,000 ppm | One chemiluminescence analyzer family; four operator-defined ranges, repeatability and linearity each better than 0.5% FS. | Applies to this NOx analyzer family only; sample conditioning, interference, calibration and certification remain application-specific. |
| Response time | T90: <2 s to 60 s (adjustable) | Operator-adjustable published range. | Not transferable to other analyzer principles or complete sampling systems. |
Delham Engineering
Send the available process data, battery limits and expected document list for a technical proposal. The engineering team will identify missing information through a structured clarification register.
